Behringer P24HUB StageConnect Hub
Hover over image to zoom in
Drag to rotate 360
(Incl. Taxes & Shipping Cost)
About This Product
Having a dedicated monitor mix engineer can be expensive and running monitor mixing from FOH can be too demanding-- neither of these is ideal. What if every musician could create their personal monitor mix with a small dedicated mixer on-stage? That's what Personal Monitoring is all about!
Save time and energy by giving the control to the musicians! Personal monitors also allow for built-in effects, improving sound; built-in microphones, improving both communication and immersion; All controlled with a simplified user interface.
Features:
- Distribution hub with StageConnect bus powering for up to 8 personal monitoring mixers
- Compatible with Behringer P24 personal mixers, AES50, Ultranet and Analog Connectivity
- 4 StageConnect front ports for powering 2 daisy-chained mixers each, minimizing on-stage cabling
- 16 balanced analog outputs on 1/4" TRS, for sending up to 8 personal stereo mixes to wireless IEM transmitters
- StageConnect 26 x 6-channel audio transmission at sub-milisecond latency, 24-Bit uncompressed PCM, 44.1/48 kHz, using a standard XLR cable (DMX cable recommended)
- StageTalk intercom system for communication between FOH, stage technician and musicians
- Stable operation range up to 40 m via DMX type XLR cable - standard microphone cable can be used for short connections
- AES50 In and Thru, with 48 x 48 channels on CAT5E STP cable up to 80 m
- Ultranet Input with 16 channels on CAT5 STP cable up to 75 m
- Ultranet In and Outputs for interfacing with various Behringer P16 personal monitoring equipment
- Integrated sample rate conversion for compatibility with 96 kHz AES50-equipped devices, such as Midas HD consoles
- Rugged 1U rackmount chassis for durability in portable applications
- Integrated auto-ranging switch-mode power supply
Specifications
- Connections: 2 × RJ45 AES50 sync HOST/Master/thru , 2 × RJ45 ULTRANET input/output, 1 × male StageConnect HOST/Master, 1 × female StageConnect CLIENT/Slave, 4 × male StageConnect remote outputs, 16 × 1/4" TRS Analog Outputs, USB Type B
- Audio Channels: 16/24 (AES50), 24 (StageConnect)
- Sample Rate: 44.1 / 48 kHz
- Bit Depth: 24 bit
- Latency: 146 μs at 44.1 Hz / 125 μs at 48 kHz
- Phantom Power: 12 V DC / 18 W
- Dimensions: 1.8" (H) × 19.0" (W) × 5.9" (D) / 44 mm (H) × 483 mm (W) × 151 mm (D)
- Weight: 2.72 kg (6.00 lbs)
PRODUCT HIGHLIGHTS
- * Ultimate Mix Control
- * Pristine 24-Bit Sound
- * Effortless Stage Connectivity
- * Built for the Stage
